Blower Motor 561-820-015-E
Доступно в магазинах 15 пропозицій
Сумісність з автомобілями 216 автомобілів
Технічні характеристики
| OEM Part Number | 561-820-015-E |
|---|---|
| Operating Voltage | 12V |
| Rotation Direction | Clockwise |
| Number of Pins | 2 |
| Plug Type | Female |
| Fan Blade Diameter | 149 mm |
| Net Weight | Approximately 1.67 kg |
| Location | Passenger side, beneath dashboard, inside HVAC housing |
| Compatible Vehicles | VW Beetle (2012–2019), VW Passat (2012–2022) |
Як замінити Blower Motor
Replacing the blower motor on a VW Beetle or Passat is a straightforward job accessible to a competent DIYer with basic hand tools. The motor sits on the passenger side under the dashboard inside the HVAC housing. Always disconnect the battery before beginning and consult your vehicle's service manual for model-specific torque values.
-
Disconnect the Battery
Open the hood and disconnect the negative (-) battery terminal. Wait at least 60 seconds before proceeding to eliminate any residual electrical charge and ensure safe working conditions.
-
Access the Passenger Footwell
Move to the passenger side of the cabin. Remove any lower dashboard trim panels or kick panels obstructing access to the HVAC blower motor housing. Retain all screws and clips in a container for reassembly.
-
Locate the Blower Motor
Identify the blower motor housing on the passenger side beneath the dashboard. The motor is the cylindrical unit with a fan blade assembly secured within the HVAC box.
-
Disconnect the Electrical Connector
Press the release tab on the 2-pin female connector and carefully pull it free from the blower motor. Avoid pulling on the wiring harness itself to prevent damage to the connector terminals.
-
Remove the Old Blower Motor
Unscrew the mounting bolts or screws securing the blower motor to the HVAC housing. Carefully extract the motor from its housing, taking care not to damage surrounding ducts or wiring.
-
Install the New Blower Motor
Position the new 561-820-015-E blower motor into the housing, aligning the mounting holes. Secure with the original mounting hardware. Consult the vehicle service manual for the correct torque specification.
-
Reconnect the Electrical Connector
Plug the 2-pin female connector back onto the new blower motor until you hear or feel it click securely into place. Route the harness clear of any moving parts.
-
Reassemble and Test
Reattach all dashboard trim panels and kick panels removed earlier. Reconnect the negative battery terminal, start the vehicle, and test the HVAC system across all fan speed settings to confirm correct operation.
Ознаки зношеної деталі
-
Unusual Noises from Vents
Rattling, squealing, or grinding sounds when the HVAC system is running often indicate worn blower motor bearings, debris caught in the fan blade, or a failing motor about to seize.
-
Reduced or No Airflow
A significant drop in airflow from all vents or a complete loss of air movement while the HVAC is active points directly to a failing or seized blower motor that can no longer spin the fan blade.
-
Inconsistent Fan Speed Operation
If the fan only works on certain speed settings or speeds feel incorrect for the selector position, the blower motor or its associated resistor may be failing. Confirm by testing each speed position.
-
HVAC System Completely Inoperative
When the blower motor fails entirely, the HVAC system produces no airflow regardless of fan speed or mode selection, leaving the cabin without heating, cooling, or ventilation.
-
Intermittent Fan Operation
The fan cutting in and out unexpectedly during operation can signal a failing blower motor with a deteriorating armature or a loose electrical connection at the 2-pin connector.
Періодичність заміни
Blower motor longevity varies widely by usage and environment. Proactive cabin air filter replacement per the standard service schedule helps reduce debris reaching the blower motor and extends its service life.
Часті запитання
Is part number 561-820-015-E compatible with my VW Beetle?
Yes, this blower motor is compatible with the Volkswagen Beetle from 2012 to 2019 across a wide range of trims and engine variants including 1.8L, 2.0L, and 2.5L gasoline engines, as well as the 2.0L TDI diesel. Always verify fitment against your specific VIN before ordering.
Does 561-820-015-E fit the VW Passat and which years?
Yes, this blower motor fits the Volkswagen Passat from 2012 through 2022, covering trims such as S, SE, SEL, SEL Premium, GT, R-Line, and Wolfsburg Edition with engines ranging from 1.8L to 3.6L gas and 2.0L TDI diesel. Confirm with your VIN for exact fitment.
What earlier part numbers does 561-820-015-E replace?
The E suffix revision supersedes three earlier OEM part numbers: 561-820-015-A, 561-820-015-B, and 561-820-015-D. If your vehicle currently has one of these older units installed, 561-820-015-E is the correct current replacement.
Is the Walker WBL01368 a reliable aftermarket alternative?
Walker WBL01368 is a direct aftermarket equivalent that matches OEM specifications including 12V operation, clockwise rotation, 2-pin female connector, and 149 mm fan blade diameter. It is a cost-effective alternative for those not requiring the OEM Volkswagen part, but confirm compatibility for your specific vehicle before purchasing.
Can I replace the blower motor myself or do I need a professional?
The replacement is considered a moderate DIY job. The motor is accessible from the passenger footwell after removing lower dash trim panels, and no special tools are required beyond basic hand tools. Disconnecting the battery beforehand is essential. Consulting the vehicle service manual for trim removal sequences and any torque specifications is strongly recommended.
Why is my new blower motor rattling after installation?
Rattling after installation is most commonly caused by debris left inside the blower housing from the failed unit, a fan blade that is not fully seated on the motor shaft, or trim panels that were not properly refastened. Remove the motor, clean the housing thoroughly, verify the fan blade is secure, and reinstall before assuming the new part is defective.
