TPMS Sensor 5Q0-998-270-F
Доступно в магазинах 7 пропозицій
Сумісність з автомобілями 213 автомобілів
Технічні характеристики
| OEM Part Number | 5Q0-998-270-F |
|---|---|
| Part Type | Direct-fit TPMS Valve Stem Sensor |
| Brand Group | Volkswagen Group (VAG) |
| Compatible Brands | Volkswagen, Audi, Škoda |
| Mounting Location | Wheel rim valve hole |
| Programming Required | Yes — must be synced to vehicle TPMS module after installation |
| Replacement Trigger | On failure, battery depletion, or physical damage |
| Sensor Count per Vehicle | Typically 4 (one per wheel) |
| Dimensions | — |
| Frequency | — |
Як замінити TPMS Sensor
Replacing the 5Q0998270F TPMS sensor requires tire demounting, sensor swap at the valve hole, tire remounting, inflation, and a TPMS programming step to register the new sensor ID with the vehicle's control module. The job can be performed at home with tire service equipment, but most owners opt for a tire shop that has a TPMS scan tool on hand.
-
Deflate the Tire Completely
Remove the valve core and allow all air to escape the tire. Confirm zero pressure before proceeding to avoid injury during tire demounting.
-
Break the Bead and Demount the Tire
Using a tire machine or bead-breaking tool, unseat both tire beads from the wheel rim and carefully remove the tire from the wheel without contacting the TPMS sensor.
-
Remove the Old TPMS Sensor
From inside the wheel, unscrew the retaining nut securing the sensor to the valve hole. Withdraw the old sensor and discard it. Inspect the valve hole for corrosion or damage.
-
Install the New 5Q0998270F Sensor
Insert the new sensor through the valve hole from the inside of the wheel, ensuring it seats flush against the rim. Thread the retaining nut by hand first to avoid cross-threading.
-
Torque the Retaining Nut
Tighten the retaining nut to the torque value specified in your vehicle's service manual. Consult the manual or dealership for the exact figure, as values vary by model and rim type.
-
Remount and Inflate the Tire
Mount the tire back onto the rim, taking care not to pinch the sensor. Inflate to the vehicle's recommended pressure as shown on the door jamb placard or owner's manual.
-
Program and Register the Sensor
Using a compatible TPMS programming tool (such as a VW/VCDS-capable scan tool or a universal TPMS relearn tool), activate the new sensor and register its unique ID with the vehicle's TPMS control module. Verify the warning light clears after a short drive.
Ознаки зношеної деталі
-
TPMS Warning Light Illuminated
The most common sign of a failed sensor is a solid or flashing TPMS indicator on the instrument cluster that does not clear after tire pressures are corrected.
-
Inaccurate or Missing Pressure Readings
The vehicle's tire pressure display shows an incorrect value for one wheel, or that wheel's reading disappears entirely from the multi-information display.
-
TPMS System Fails to Reset
After inflating all tires to the correct pressure and attempting a manual reset, the warning light refuses to extinguish, indicating the sensor is no longer transmitting a valid signal.
-
Intermittent or Erratic Pressure Data
Tire pressure readings fluctuate randomly or drop out temporarily, often pointing to a failing sensor battery or damaged sensor electronics.
-
Fault Code Stored in TPMS Module
A diagnostic scan reveals a stored fault code referencing a specific wheel's sensor, confirming the sensor is not communicating with the control module.
Періодичність заміни
TPMS sensor internal batteries are not serviceable. Once battery voltage drops below operating threshold — typically after 5 to 10 years depending on transmission frequency and climate — the entire sensor unit must be replaced. Proactively replacing all four sensors simultaneously during a full tire set replacement is cost-effective.
Часті запитання
Does the 5Q0998270F sensor need to be programmed after installation?
Yes. Every TPMS sensor has a unique ID code that must be registered with the vehicle's TPMS control module. After installation you will need a compatible TPMS relearn tool or a VW-capable OBD-II scan tool to complete the registration. Without this step the warning light will remain on even though the tire pressure is correct.
Which vehicles is the 5Q0998270F compatible with?
This sensor is used across multiple Volkswagen Group brands including Volkswagen, Audi, and Škoda. Because the VAG group shares many platforms, the exact compatibility list is broad. Always verify fitment using your vehicle's full VIN through a VW dealership parts lookup or a trusted fitment database before ordering.
Can I use an aftermarket TPMS sensor instead of the OEM part?
Yes. Aftermarket equivalents such as the VEMO V10-72-0388 are listed as direct replacements and are generally less expensive. The trade-off is that some aftermarket sensors may require an additional programming step or a universal TPMS tool rather than simply being read by the factory scan tool. OEM sensors from a VW dealership offer the most straightforward plug-and-play experience.
How long do TPMS sensor batteries last?
The internal lithium battery in a TPMS sensor typically lasts between 5 and 10 years depending on transmission frequency, temperature extremes, and driving patterns. The battery is not replaceable — when it depletes, the entire sensor unit must be swapped out.
Do I need to replace all four sensors at the same time?
You are only required to replace the failed sensor, but if your vehicle is several years old and one sensor battery has depleted, the remaining three are likely nearing end of life as well. Replacing all four during the same tire service visit saves repeated labour costs and keeps all sensors synchronized in age.
What is the difference between part suffix -270-F and earlier suffix variants like -270-E?
Volkswagen Group periodically supersedes TPMS sensor part numbers when design or firmware revisions are made. The -F suffix represents the current superseded revision. Always order the latest suffix available, as it is designed to replace all earlier variants and will be the version stocked by dealerships.
